Fixed Thermostat
TS-SF Series
This is an automatic reset thermostat that has a fixed temperature type
that only operates at specific temperatures.
The TS-SF Series is widely used in products that need to operates
at specific temperatures and overheating needs to be prevented.
The temperature can be set up to a maximum of 320°C.
Features
- Automatic Reset / Fixed Temperature
- Temp Range : Max. 320°C (608°F)
- Switch Life Cycle : 100,000 Cycles
- Bulb & Capillary Tube : 300 Series Stainless Steel
- Capillary Tube Length : 1,000mm
- (250mm to 2,000mm)
- Electric Rating : 20A/250VAC
- Switch Type : SPST, SPDT
Applications
- Commercial Kitchen Equipment
- Heating & Cooling Equipment
- Industrial Facilities
- Experimental Equipment
Main Model
Model
Temp Range
Electric Ratings
Bulb Dimensions
Switch
Accuracy
-
TS-120SF BASIC TYPE
-
TS-120SF-C with PLUG
-
TS-220SF BASIC TYPE
-
TS-220SF-C with PLUG
